Acura RSX I (2001-2004) front stereo amplifier rear stereo amplifier relay Wiring diagram
This page shows the only wiring diagram for the component.front stereo amplifier rear stereo amplifier relay, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front stereo amplifier rear stereo amplifier relay (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C COMPRESSOR CLUTCH RELAY A/C CONDENSER FAN RELAY RADIATOR FAN RELAY
A/C CONDENSER FAN RELAY
A/F SENSOR RELAY
ABS MODULATOR CONTROL UNIT CLIMATE CONTROL UNIT
ALTERNATOR
BATTERY
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLOWER MOTOR RELAY REAR WINDOW DEFOGGER RELAY
BLU WIRE
CANADA
CARGO AREA LIGHT
DRL CONTROL UNIT
ELECTRICAL LOAD DETECTOR (ELD) UNIT
EXCEPT CANADA BASE
FRONT STEREO AMPLIFIER REAR STEREO AMPLIFIER RELAY
FUSE 1
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 19
FUSE 2
FUSE 2 FUSE 4
FUSE 20
FUSE 3
FUSE 7
GRN WIRE
IGNITION KEY SWITCH KEY LIGHT CEILING LIGHT SPOTLIGHT
IGNITION SWITCH
MOONROOF CLOSE RELAY
MOONROOF OPEN RELAY
MULTIPLEX CONTROL UNIT
ON (II) (I)
POWER MIRROR SWITCH
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RECIRCULATION CONTROL MOTOR SEAT HEATER RELAY
RED WIRE
RED/BLK WIRE
SEAT HEATER RELAY
STARTER
STARTER SOLENOID
TAILLIGHT RELAY
TO FUSE 1 (DIAGRAM 3 OF 4)
TO FUSE 3 (DIAGRAM 4 OF 4)
TO FUSE 5 (DIAGRAM 2 OF 4)
TO FUSE 8 (DIAGRAM 4 OF 4)
TO FUSE 9 (DIAGRAM 2 OF 4)
TO HEADLIGHT RELAY 1 (DIAGRAM 2 OF 4)
TO POWER WINDOW RELAY (DIAGRAM 2 OF 4)
TO STARTER CUT RELAY (DIAGRAM 4 OF 4)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/ RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WITH BOSE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 4) -> FRONT STEREO AMPLIFIER REAR STEREO AMPLIFIER RELAY
