Acura RSX I (2001-2004) fls - scs rls - rr + wiring diagram
This page shows the only wiring diagram for the component.fls - scs rls - rr +, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fls - scs rls - rr + wiring diagram (1 of 1)
ABS INDICATOR
ABS INDICATOR CIRCUIT
ABS MODULATOR CONTROL UNIT (RIGHT FRONT OF ENGINE COMPARTMENT)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SWITCH (ON PEDAL BRACKET, ABOVE BRAKE PEDAL)
BRN WIRE
BRN/WHT WIRE
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR (DLC) (IN FRONT CONSOLE, BEHIND ASHTRAY)
FLS - SCS RLS - RR +
FRS
FRS - FRS+ STOP RLS+ RR- WALP FRS +B MR +B DLC
FUSE 10
FUSE 11
FUSE 8
GAUGE ASSEMBLY
GND 1 GND 2
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN TIMES
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENG COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit -> FLS - SCS RLS - RR +
