Acura RL II facelift (2008-2012) Seat ventilation circuit, driver"s

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE DRIVER'S SEAT BACK INNER FAN MOTOR DRIVER'S SEAT BACK OUTER FAN MOTOR DRIVER'S SEAT CUSHION FRONT FAN MOTOR DRIVER'S SEAT CUSHION REAR FAN MOTOR DRIVER'S SEAT HEATER CUSHION HEATER DRIVER'S SEAT VENTILATION CONTROL UNIT (UNDER DRIVER'S SEAT) DRIVER'S SEAT VENTILATION SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FAN INDICATOR FRONT SEAT HEATER RELAY FUSE 21 FUSE 30 FUSE 6 GRN WIRE HEATER INDICATOR HOT AT ALL TIMES HOT IN ON HOT IN ON OR START HTR TH(-) TH(+) CUSH FAN RR BACK FAN CUSH FAN FR HTRH HTRM HTRL BLRH BLRM BLRL ILL(+) LT BLU WIRE LT GRN WIRE MEMORY SYSTEMS ORG/ WIRE PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE PPL RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SEAT BACK HEATER SG 1 PG 1 SW UP SW DN SWITCH SWITCH LIGHT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
