Acura RL II facelift (2008-2012) w/o w/ technology technology package package Wiring diagram
This page shows the only wiring diagram for the component.w/o w/ technology technology package package, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o w/ technology technology package package (1 of 1)
2) AUTO 3) HEAD
AFS INDICATOR
AUTO ATPR LT SIO LT SIG
AUTO AUTO LT SIP B-CAN
AUTOMATIC LIGHTING SENSOR/SUNLIGHT SENSOR (FRONT CENTER OF DASH)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 11
FUSE 21
FUSE 29
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
HEADLIGHT SWITCH 0) OFF 1) PARK
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
MICU
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
RED/BLK WIRE
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
VBU
W/O W/ TECHNOLOGY TECHNOLOGY PACKAGE PACKAGE
WARNING DRIVE CIRCUIT
WHT WIRE
WIPER/ WASHER SWITCH
Go to component -> Adaptive front lighting circuit (1 of 2) -> W/O W/ TECHNOLOGY TECHNOLOGY PACKAGE PACKAGE
