Acura RL II facelift (2008-2012) uart vbu heat Wiring diagram
This page shows the only wiring diagram for the component.uart vbu heat, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram uart vbu heat (1 of 1)
B-CAN GROUND
BLK WIRE
BLU WIRE
BOX (LEFT REAR OF ENGINE COMPT)
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
DEFOGGER
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
EXCEPT BASE BASE
EXTERIOR LIGHTS SYSTEM PPL PPL
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
FUSE 14
FUSE 2
FUSE 30
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
J/C
LEFT POWER MIRROR (IN DRIVER'S DOOR)
LT GRN WIRE
MICU
NOISE REDUCTION CONDENSER (IN RIGHT "C" PILLAR)
ORG/ WIRE
P-IG
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER/ POWER MIRROR HEATER SWITCH
RELAY CONTROL MODULE
RIGHT POWER MIRROR
RIGHT REAR POWER WINDOW SWITCH
RR DEF
UART
UART B-CAN VBU HEAT
UART VBU HEAT
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> UART VBU HEAT
