Acura RL II facelift (2008-2012) turn turn sw sw l l turn gnd Wiring diagram
This page shows the only wiring diagram for the component.turn turn sw sw l l turn gnd, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn turn sw sw l l turn gnd (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX
GAUGE CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HAZARD SW
HAZARD WARNING SWITCH LIGHT
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
L TURN LT
LEFT BRAKE LIGHT (14)
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE MARKER LIGHT
LEFT TAILLIGHT (14)
LEFT TURN SIGNAL INDICATOR
LT BLU WIRE
LT GRN WIRE
MICU
R TURN
R TURN LT
RED WIRE
RIGHT BRAKE LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAILLIGHT (14)
RIGHT TURN SIGNAL INDICATOR
TURN SIGNAL/ HAZARD RELAY 1 +B HZD
TURN TURN SW L PG SW R
TURN TURN SW SW L L TURN GND
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, with cmbs/pax; elite package (2 of 3) -> TURN TURN SW SW L L TURN GND
