Acura RL II facelift (2008-2012) trunk lid outer handle switch Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid outer handle switch, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
trunk lid outer handle switch wiring diagram (1 of 4)
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR LF ANTENNA
DRIVER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (IN DRIVER'S (BEHIND LEFT DOOR) KICK PANEL)
FRONT PASSENGER'S DOOR LF ANTENNA
FRONT PASSENGER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
FUSE 19
GRN WIRE
GRY WIRE
HOT IN ON OR START
IMMOBILIZER CIRCUIT
J/C
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OUTER HANDLE TOUCH SENSOR/ DOOR LOCK BUTTON
PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
PNK PNK WIRE
PNK WIRE
PPL
PPL 4
RED WIRE
RED/WHT WIRE
TRUNK LID OUTER HANDLE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (4 of 5) -> TRUNK LID OUTER HANDLE SWITCH
trunk lid outer handle switch wiring diagram (2 of 4)
ACTIVE NOISE CANCE- LLATION UNIT
ACURALINK CONTROL UNIT (USA: TECHNOLOGY PACKAGES CMBS/ PAX PACKAGE)
BLK WIRE
CANCE- LLATION MICROPHONE
CENTER REAR HEADREST ACTUATOR
FRONT ACTIVE NOISE CANCE- LLATION MICROPHONE
FRONT PASSENGER'S LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER (W/ BASE)
FRONT PASSENGER'S SEAT HEATER SWITCH (W/ BASE)
FUEL FILL DOOR OPENER SOLENOID
HANDS FREE LINK CONTROL UNIT
J/C
LEFT BACKUP LIGHT
LEFT REAR HEADREST ACTUATOR
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT HEATER (CANADA)
LEFT RIGHT LICENSE PLATE LIGHT LICENSE PLATE LIGHT
NAVIGATION DISPLAY UNIT
NAVIGATION UNIT
ODS UNIT
POWER REAR WINDOW SUNSHADE CONTROL UNIT
REAR ACTIVE NOISE
RIGHT BACKUP LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
RIGHT REAR HEADREST ACTUATOR
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH (NOT USED)
RIGHT REAR SEAT BACK HEATER
RIGHT REAR SEAT HEATER (CANADA)
SH-AWD CONTROL UNIT
SH-AWD RELAY
STEREO AMPLIFIER
TPMS CONTROL UNIT
TRUNK LID OUTER HANDLE SWITCH
Go to component -> Ground distribution circuit (5 of 5) -> TRUNK LID OUTER HANDLE SWITCH
trunk lid outer handle switch wiring diagram (3 of 4)
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR LF ANTENNA
DRIVER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (IN DRIVER'S (BEHIND LEFT DOOR) KICK PANEL)
FRONT PASSENGER'S DOOR LF ANTENNA
FRONT PASSENGER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
FUSE 19
GRN WIRE
GRY WIRE
HOT IN ON OR START
IMMOBILIZER CIRCUIT
J/C
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OUTER HANDLE TOUCH SENSOR/ DOOR LOCK BUTTON
PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
PNK PNK WIRE
PNK WIRE
PPL
PPL 4
RED WIRE
RED/WHT WIRE
TRUNK LID OUTER HANDLE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (4 of 5) -> TRUNK LID OUTER HANDLE SWITCH
trunk lid outer handle switch wiring diagram (4 of 4)
B+ DOOR LOCK
B-CAN
BLK WIRE
BLK/RED WIRE
BOX (BEHIND LEFT KICK PANEL)
DRIVER'S MPCS UNIT
DRIVER'S UNDER-DASH FUSE/RELAY
FUSE 27
FUSE 7
FUSE 8
GRN WIRE
HOT AT ALL TIMES
J/C
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MICU 1 VBU
PNK WIRE
TRUNK ACT
TRUNK HANDLE SW
TRUNK LID LATCH SWITCH/ OPENER SOLENOID (CENTER REAR OF TRUNK)
TRUNK LID OPENER MAIN SWITCH
TRUNK LID OPENER SOLENOID
TRUNK LID OPENER SWITCH
TRUNK LID OPENER/FUEL LID OPENER SWITCH
TRUNK LID OUTER HANDLE SWITCH
TRUNK MAIN SW
TRUNK TRUNK, FUEL OPEN OPEN ILL
VBU
VBU 2
VMP
WHT WIRE
YEL WIRE
Go to component -> Trunk release circuit -> TRUNK LID OUTER HANDLE SWITCH
