Acura RL II facelift (2008-2012) tr hndl sw ext r - ext r + ext ti - ext ti + Wiring diagrams
This page contains all the electrical diagrams for the component. tr hndl sw ext r - ext r + ext ti - ext ti +, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tr hndl sw ext r - ext r + ext ti - ext ti + (1 of 2)
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
EXT F - EXT F + EXT FR AS + RXVCC 1 TXVCC 1 RSSI 1
EXT FR AS - RFRXD 1 RFTXD 1
EXT FR DR - EXT FR DR + EXT TR - EXT TR + RSSI 2 RFRXD 2 RFTXD 2
FRONT INTERIOR KEYLESS ACCESS LF ANTENNA (BEHIND MIDDLE OF DASH)
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IGNITION SWITCH CONTROL UNIT
KEY SW HBRK SW KEY OUT IMMOCONT
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
KEYLESS ACCESS RF UNIT 1 (BEHIND MIDDLE OF DASH)
KEYLESS ACCESS RF UNIT 2 (MIDDLE OF REAR SHELF)
KNOB LOCK SOLENOID
KNOB SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
REAR BUMPER LF ANTENNA (BEHIND MIDDLE OF REAR BUMPER)
REAR INTERIOR KEYLESS ACCESS LF ANTENNA (UNDER REAR OF CENTER CONSOLE)
REAR SHELF KEYLESS ACCESS LF ANTENNA
RED WIRE
RF GND 1
RF GND 2 RXVCC 2 TXVCC 2
ROTATE SW KNOB SW IMMOBI LAMP DIAG H S NET IGN TRX
ROTATE SWITCH
SCS IGN CONT
SMART MIL
TR HNDL SW EXT R - EXT R + EXT TI - EXT TI +
TS FR AS DL FR AS
TS FR DR DL FR DR
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (5 of 5) -> TR HNDL SW EXT R - EXT R + EXT TI - EXT TI +
Wiring diagram tr hndl sw ext r - ext r + ext ti - ext ti + (2 of 2)
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
EXT F - EXT F + EXT FR AS + RXVCC 1 TXVCC 1 RSSI 1
EXT FR AS - RFRXD 1 RFTXD 1
EXT FR DR - EXT FR DR + EXT TR - EXT TR + RSSI 2 RFRXD 2 RFTXD 2
FRONT INTERIOR KEYLESS ACCESS LF ANTENNA (BEHIND MIDDLE OF DASH)
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IGNITION SWITCH CONTROL UNIT
KEY SW HBRK SW KEY OUT IMMOCONT
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
KEYLESS ACCESS RF UNIT 1 (BEHIND MIDDLE OF DASH)
KEYLESS ACCESS RF UNIT 2 (MIDDLE OF REAR SHELF)
KNOB LOCK SOLENOID
KNOB SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
REAR BUMPER LF ANTENNA (BEHIND MIDDLE OF REAR BUMPER)
REAR INTERIOR KEYLESS ACCESS LF ANTENNA (UNDER REAR OF CENTER CONSOLE)
REAR SHELF KEYLESS ACCESS LF ANTENNA
RED WIRE
RF GND 1
RF GND 2 RXVCC 2 TXVCC 2
ROTATE SW KNOB SW IMMOBI LAMP DIAG H S NET IGN TRX
ROTATE SWITCH
SCS IGN CONT
SMART MIL
TR HNDL SW EXT R - EXT R + EXT TI - EXT TI +
TS FR AS DL FR AS
TS FR DR DL FR DR
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (5 of 5) -> TR HNDL SW EXT R - EXT R + EXT TI - EXT TI +
