Acura RL II facelift (2008-2012) supplemental restraints, engine controls systems Wiring diagrams
This page contains all the electrical diagrams for the component. supplemental restraints, engine controls systems, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram supplemental restraints, engine controls systems (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
DLC (UNDER LEFT SIDE OF DASH)
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S DOOR LOCK SWITCH
FRONT PASSENGER'S DOOR SWITCH
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
IMMOBILIZER CONTROL UNIT- RECEIVER (ON RIGHT SIDE OF STEERING COLUMN)
IMMOCONT
IMOES UNIT (UNDER MIDDLE OF DASH)
IMOLMP
J/C
KEY OUT
LOCK
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
PPL
RED WIRE
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR SWITCH
RIGHT REAR POWER WINDOW SWITCH
S-NET
SUPPLEMENTAL RESTRAINTS, ENGINE CONTROLS SYSTEMS
UART +B DR SW PG SGND
UNLOCK
VBU 1 REMOTE ILL UNLOCK LOCK ILL (+) VBU UART UNLCK UNLCK AS DR SW SG PG
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (3 of 5) -> SUPPLEMENTAL RESTRAINTS, ENGINE CONTROLS SYSTEMS
