Acura RL II facelift (2008-2012) stop sw atp-p b-can wiring diagram
This page shows the only wiring diagram for the component.stop sw atp-p b-can, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop sw atp-p b-can wiring diagram (1 of 1)
APP SENSOR (UNDER LEFT SIDE OF DASH)
APSB
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (NEAR BRAKE PEDAL)
BRN WIRE
CUT RELAY
DRIVER'S AUXILIARY UNDER-DASH RELAY BOX (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGNITION KEY SWITCH
IGNITION SWITCH CONTROL UNIT
J/C
J/C (UNDER LEFT SIDE OF (UNDER DASH) CENTER CONSOLE)
KEY INTERLOCK SOLENOID
KEY SOL
KEY SW B-CAN
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MICU
P-PIN
PARK PIN SWITCH
PCM (UNDER MIDDLE OF DASH)
PNK SLS BKSW ATP-N ATP-P WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL APSA
RED WIRE
RED/BLK WIRE
SEATS SYSTEM
SHIFT LOCK SOLENOID
STOP SW ATP-P B-CAN
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 13
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> STOP SW ATP-P B-CAN
