Acura RL II facelift (2008-2012) solenoid 1) trunk open Wiring diagram
This page shows the only wiring diagram for the component.solenoid 1) trunk open, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram solenoid 1) trunk open (1 of 1)
ACTIVE NOISE CONTROL UNIT (RIGHT SIDE OF TRUNK)
B-CAN INTR LT
BLK WIRE
BOX (BEHIND LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOCK SWITCH
DRIVER'S DOOR OUTER HANDLE LIGHT/TOUCH SENSOR
DRIVER'S DOOR POCKET DRIVER'S LIGHT DOOR COURTESY LIGHT
DRIVER'S FOOTWELL LIGHT
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
DRIVER'S UNDER-DASH
DRIVER'S UNDER-DASH FUSE/RELAY
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVING POSITION MEMORY SWITCH
FRONT PASSENGER'S FOOTWELL LIGHT
FUSE 6
FUSE 7
FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MAP
MEMORY SYSTEM
MICU FOOT LT LT OFF
PNK (BEHIND LEFT SIDE OF DASH) WIRE
PNK WIRE
PPL
RED WIRE
SOLENOID 1) TRUNK OPEN
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM
TRUNK LID LATCH SWITCH/OPENER
TRUNK LID LIGHT SWITCH
TRUNK LID OPENER/ FUEL LID OPENER SWITCH
TRUNK LIGHT A
TRUNK LIGHT B
VBU B-CAN
WHT WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> SOLENOID 1) TRUNK OPEN
