Acura RL II facelift (2008-2012) rf lf sig rr lf sig lf lf sig lr lf sig Wiring diagram
This page shows the only wiring diagram for the component.rf lf sig rr lf sig lf lf sig lr lf sig, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf lf sig rr lf sig lf lf sig lr lf sig (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES CANH SYSTEM
COMPUTER DATA LINES SYSTEM
COMPUTER K-LINE CANL DATA LINES SYSTEM
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE
FUSE 15
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
LEFT FRONT TPMS INITIATOR (BEHIND LEFT SIDE OF FRONT BUMPER)
LEFT REAR TPMS INITIATOR (ON LEFT REAR FENDERWELL)
LF LF GND RF LF GND LR LF GND RR LF GND PNK WIRE
LF LF PWR RF LF PWR LR LF PWR RR LF PWR
LOW TIRE PRESSURE INDICATOR
LT BLU WIRE
LT GRN WIRE
LT PNK WIRE
MULTI- INFORMATION DISPLAY (MID) UNIT TPMS INDICATOR
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK LT WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
RF LF SIG RR LF SIG LF LF SIG LR LF SIG
RIGHT FRONT TPMS INITIATOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
RIGHT REAR TPMS INITIATOR (ON RIGHT REAR FENDERWELL)
TPMS CONTROL UNIT (RIGHT SIDE OF REAR SHELF)
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> RF LF SIG RR LF SIG LF LF SIG LR LF SIG
