Acura RL II facelift (2008-2012) rear power window sunshade control unit Wiring diagram
This page shows the only wiring diagram for the component.rear power window sunshade control unit, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear power window sunshade control unit (1 of 1)
ALTERNATOR ENGINE MOUNT CONTROL SOLENOID VALVE
AUTOMATIC DIMMING INSIDE MIRROR PCM
BLK WIRE
BLU WIRE
CANADA USA
DRIVER'S MPCS UNIT
DRIVER'S SEAT BELT TENSION REDUCER SOLENOID
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECPS DRL CONTROL CONTROL UNIT UNIT
EVAP CANISTER PURGE VALVE
FROM FUSE 29 (DIAGRAM 4 OF 5)
FROM IGNITION SWITCH (DIAGRAM 2 OF 6)
FUSE 10
FUSE 11
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 29 FUSE 31
GRN WIRE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
J/C
KEYLESS
MAF/IAT PCM SENSOR
MICU
ODS UNIT
ORG/ WIRE
PGM-FI MAIN RELAY 2
PNK PNK WIRE
PNK WIRE
REAR POWER WINDOW SUNSHADE CONTROL UNIT
RED WIRE
SH-AWD CONTROL UNIT UNIT (USA: CMBS/ PAX PACKAGE) (CANADA: PREMIUM PACKAGE)
SHFT LOCK SOLENOID
SRS UNIT IMOES ACCESS UNIT CONTROL UNIT
STEERING ANGLE SENSOR
TO FUSE 18 (DIAGRAM 4 OF 6)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
USA CANADA
VSA MODULATOR CONTROL UNIT
WHT WIRE
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit (4 of 6) -> REAR POWER WINDOW SUNSHADE CONTROL UNIT
