Acura RL II facelift (2008-2012) ppl ctrl mtr rly com pwr Wiring diagram
This page shows the only wiring diagram for the component.ppl ctrl mtr rly com pwr, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl ctrl mtr rly com pwr (1 of 1)
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
A/C PRESSURE SENSOR (RIGHT SIDE OF ENGINE COMPT)
ASPIRATOR FAN
AUTOMATIC LIGHTING SENSOR/ SUNLIGHT SENSOR (FRONT CENTER OF DASH)
B-CAN B-CAN
BLK WIRE
BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
BLOWER POWER TRANSISTOR (BEHIND RIGHT SIDE OF DASH, LEFT OF BLOWER MOTOR)
BLU WIRE
BLU/RED WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRIVER'S VENT AIR TEMPERATURE SENSOR (BEHIND LEFT SIDE OF GAUGE CONTROL MODULE)
FRONT PASSENGER'S VENT AIR TEMPERATURE SENSOR (UNDER RIGHT SIDE OF DASH)
FUSE 30
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HVAC CONTROL MOTOR RELAY
IN-CAR TEMPERATURE SENSOR (ON DASH, RIGHT OF STEERING COLUMN)
J/C
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
PPL CTRL MTR RLY COM PWR
PRESS SNSR TEMP SENS TEMP SENS TEMP SENS SUNLIGHT SENS
RED WIRE
RED/BLK WIRE
SEATS SYSTEM
SO AC CLK AC GND COM GND SENS COM
SOL IN SOL OUT CTRL MTR RLY SO SI CLK BLWR FEEDBACK TRANS CTRL
TEMP SENS TEMP SENS
TEMPERATURE SENSOR
VARIABLE CAPACITY CONTROL SOLENOID VALVE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> PPL CTRL MTR RLY COM PWR
