Acura RL II facelift (2008-2012) power seats system Wiring diagram
This page shows the only wiring diagram for the component.power seats system, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power seats system (1 of 1)
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
BUCK- LED
CABLE REAL (ON STEERING COLUMN)
CANADA
CDS GNDA GNDB K-LINE
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
DRIVER'S SEAT BELT BUCKLE BUCK- LED UN- SWITCH BUCK- LED (UNDER DRIVER'S SEAT)
DRIVER'S SEAT BELT TENSIONER CONNECTOR (AT BASE OF LEFT "B" PILLAR)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S SEAT BELT TENSIONER CONNECTOR (AT BASE OF RIGHT "B" PILLAR)
FUSE 10
FUSE 21
FUSE 22
GRN WIRE
GRY WIRE
HOT IN ON OR START
IDC PTT HP_UART ODS LFS- RFS- IGN IN IGN IN
J/C
LBSC LBSO
LFS+ RFS+
LRP+ LRP- RRP+ RRP- SS- SS+
LT BLU WIRE
LT GRN WIRE
MES SCS
ORG/ WIRE
PNK PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWER SEATS SYSTEM
RBSC RBSO
RED WIRE
RED/WHT WIRE
SHIFT INTERLOCK, WIPER/WASHER, MEMORY SYSTEMS
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
STEERING WHEEL)
VIO WIRE
WARNING SYSTEMS
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Supplemental restraints circuit (1 of 4) -> POWER SEATS SYSTEM
