Acura RL II facelift (2008-2012) micu service check connector Wiring diagrams
This page contains all the electrical diagrams for the component. micu service check connector, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram micu service check connector (1 of 3)
+B B-CAN
23 24 VBU TRUNK MAIN SW
ATP-R CDS MIRROR R
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
FUSE 21 FUSE 8
FUSE 3
FUSE 30
FUSE 32
FUSE 7
GRN WIRE
GRY WIRE
H/L CLEAN SW
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON
HOT IN ON OR START
INTERIOR LIGHTS SYSTEM WIPER/WASHER SYSTEM
INTR LT 11 12 13 14 15 16 17 18 19 20 21 SG-2 CHK KEY LT
LT BLU WIRE
LT GRN WIRE
MAP LT OFF
MEMORY SYSTEMS
MICU DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
MICU SERVICE CHECK CONNECTOR
MIRROR LT MIRROR RT AUTO LT SID HAZARD SW KEYLESS BUZZER AUTO LT SIG
ORG/ WIRE
PNK PPL WIRE
PNK WIRE
PPL
PPL PPL
RED WIRE
SEAT BELT SW-
SG-1 P-PIN H/L BACKUP FUEL LID BACK LT DLC
SHIFT INTERLOCK SYSTEM HEADLIGHTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM
STOP SW
TRANSMISSIONS SYSTEM
TRUNK HANDLE SW
TRUNK SW
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TURN SIGNAL/ HAZARD RELAY 1
WHT WIRE
WIPER/WASHER SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit -> MICU SERVICE CHECK CONNECTOR
Wiring diagram micu service check connector (2 of 3)
ACCESSORY POWER SOCKET RELAY
AUTO- DRIVER'S VANITY MIRROR LIGHT MATIC DIMMING INSIDE MIRROR
BLK WIRE
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
DRIVER'S DOOR OUTER HANDLE LIGHT/TOUCH SENSOR
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S MPCS UNIT
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER (W/ BASE)
DRIVER'S SEAT HEATER SWITCH (W/ BASE)
DRIVER'S SEAT- BACK HEATER
FRONT PASSE- NGER'S VANITY
HIGH MOUNT BRAKE LIGHT
LEFT POWER DRIVING POSITION MEMORY SWITCH MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
MICU
MICU SERVICE CHECK CONNECTOR
MIRROR LIGHT
MOONROOF CONTROL UNIT
NCA WIRE
PG SG-2 GND
PPL
REAR INDIVIDUAL MAP LIGHTS
ROOF CONSOLE
TRUNK LID OPENER/ FUEL LID OPENER SWITCH
TURN SIGNAL/ HAZARD RELAY 1 GND
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 5) -> MICU SERVICE CHECK CONNECTOR
Wiring diagram micu service check connector (3 of 3)
ADAPTIVE CRUISE CONTROL UNIT (BEHIND RIGHT SIDE OF DASH)
ADAPTIVE FRONT LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
B- CHK CAN
BASE
BLK WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
CAN L USA: BASE TECHNOLOGY PACKAGE; CANADA: BASE
CLIMATE CONTROL UNIT
COMBINATION SWITCH CONTROL UNIT WIPER/WASHER SWITCH
CONTROL BLOCK
DLC (DATA LINK CONNECTOR) (UNDER LEFT SIDE OF DASH)
DOOR
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
DRIVER'S POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
EXCEPT BASE
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
J/C
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LT GRN WIRE
MICU
MICU SERVICE CHECK CONNECTOR
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
RIGHT REAR POWER WINDOW SWITCH
SEAT)
SG-2
STEERING ANGLE SENSOR (ON SIDE OF STEERING COLUMN)
UART CAN
USA: CMBS/PAX PACKAGE; CANADA: PREMIUM PACKAGE
VSA MODULATOR CONTROL UNIT (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> High/low bus circuit (1 of 2) -> MICU SERVICE CHECK CONNECTOR
