Acura RL II facelift (2008-2012) light/ touch sensor Wiring diagram
This page shows the only wiring diagram for the component.light/ touch sensor, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light/ touch sensor (1 of 1)
BATTERY
BLK WIRE
BLOWER POWER TRANSISTOR
BLU WIRE
BRAIDED WIRE
BRN WIRE
COIN POCKET LIGHT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
E-PRETENSIONER UNIT (USA: CMBS/ PAX PACKAGE) (CANADA: PREMIUM PACKAGE)
FRONT PASSENGER'S MPCS UNIT
FRONT SEAT HEATER RELAY
FUEL FILL DOOR OPENER RELAY
FUEL PUMP CONTROL MODULE
FUSE/RELAY HEADLIGHT BOX WASHER (BEHIND RIGHT RELAY KICK PANEL) (CANADA)
GLOVE BOX LIGHT
INTERFACE DIAL
J/C
KEYLESS ANSWER BACK BUZZER
KNOB SWITCH/ DOOR SWITCH
LEFT BRAKE LIGHT/ TAILLIGHT
LIGHT/ TOUCH SENSOR
LOCK ACTUATOR
MES CONNECTOR
MICU
NOISE REDUCTION CONDENSER
OPENER SOLENOID
OUTER HANDLE
PASSENGER'S UNDER-DASH
PPL
REAR WINDOW DEFOGGER
RED WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT POWER MIRROR
RIGHT SIDE ENGINE MOUNT
SRS UNIT
STEERING ANGLE SENSOR
TRANSMISSION
TRUNK LID LATCH SWITCH
TRUNK LID OPENER MAIN SWITCH
WHT WIRE
XM ANTENNA/ XM RECEIVER SHIELD (USA: BASE, CANADA) XM ANTENNA/
Go to component -> Ground distribution circuit (1 of 5) -> LIGHT/ TOUCH SENSOR
