Acura RL II facelift (2008-2012) lhss ssr b-can ssr ppl Wiring diagram
This page shows the only wiring diagram for the component.lhss ssr b-can ssr ppl, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lhss ssr b-can ssr ppl (1 of 1)
ADAPTIVE FRONT LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
AFS OFF SWITCH
AG HSG HSV RHSS PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
GRN WIRE
GRY WIRE
HALL SENSOR
LEFT ADAPTIVE FRONT LIGHTING GEARBOX (BEHIND LEFT HEADLIGHT ASSEMBLY)
LHSS SSR B-CAN SSR PPL
LT BLU WIRE
LT GRN WIRE
PNK AS SV WIRE
PNK WIRE
PPL
PPL AFS OFF SW SCS
RED WIRE
RELAY CONTROL MODULE
RIGHT ADAPTIVE FRONT LIGHTING GEARBOX (BEHIND RIGHT HEADLIGHT ASSEMBLY)
STEPPER MOTOR
SUSPENSION STROKE SENSOR (UNDER LEFT REAR OF VEHICLE)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Adaptive front lighting circuit (2 of 2) -> LHSS SSR B-CAN SSR PPL
