Acura RL II facelift (2008-2012) left rear turn signal light Wiring diagrams
This page contains all the electrical diagrams for the component. left rear turn signal light, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear turn signal light (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX
GAUGE CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HAZARD SW
HAZARD WARNING SWITCH LIGHT
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
L TURN LT
LEFT BRAKE LIGHT (14)
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE MARKER LIGHT
LEFT TAILLIGHT (14)
LEFT TURN SIGNAL INDICATOR
LT BLU WIRE
LT GRN WIRE
MICU
R TURN
R TURN LT
RED WIRE
RIGHT BRAKE LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAILLIGHT (14)
RIGHT TURN SIGNAL INDICATOR
TURN SIGNAL/ HAZARD RELAY 1 +B HZD
TURN TURN SW L PG SW R
TURN TURN SW SW L L TURN GND
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, with cmbs/pax; elite package (2 of 3) -> LEFT REAR TURN SIGNAL LIGHT
Wiring diagram left rear turn signal light (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX
GAUGE CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HAZARD SW
HAZARD WARNING SWITCH LIGHT
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
L TURN
L TURN GND
LEFT BRAKE LIGHT (14)
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE MARKER LIGHT
LEFT TAILLIGHT (14)
LEFT TURN SIGNAL INDICATOR
LT BLU WIRE
LT GRN WIRE
MICU
R TURN
RED WIRE
RIGHT BRAKE LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAILLIGHT (14)
RIGHT TURN SIGNAL INDICATOR
TURN +B SIGNAL/ HAZ HAZARD RELAY 1 R TURN
TURN PG SW L
TURN SW L
TURN SW R
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, without cmbs/pax; elite package (2 of 3) -> LEFT REAR TURN SIGNAL LIGHT
