Acura RL II facelift (2008-2012) left front parking light Wiring diagrams
This page contains all the electrical diagrams for the component. left front parking light, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front parking light (1 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
DEFOGGER SYSTEM
FUSE 13
FUSE 16
FUSE 4
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LEFT FRONT PARKING LIGHT
LEFT LICENSE PLATE LIGHT
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
PPL DEFOGGER SYSTEM
RELAY CONTROL MODULE
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT POWER MIRROR
RIGHT SIDE TURN SIGNAL LIGHT
TAILLIGHT RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, with cmbs/pax; elite package (3 of 3) -> LEFT FRONT PARKING LIGHT
Wiring diagram left front parking light (2 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
DEFOGGER SYSTEM
FUSE 13
FUSE 16
FUSE 4
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LEFT FRONT PARKING LIGHT
LEFT LICENSE PLATE LIGHT
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
PPL DEFOGGER SYSTEM
RELAY CONTROL MODULE
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT POWER MIRROR
RIGHT SIDE TURN SIGNAL LIGHT
TAILLIGHT RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, without cmbs/pax; elite package (3 of 3) -> LEFT FRONT PARKING LIGHT
Wiring diagram left front parking light (3 of 4)
BLK WIRE
BLK/RED WIRE
BRIGHTENING SWITCH DIMMING SWITCH
COMBINATION LIGHT SWITCH
CONTROL BLOCK
DASH LIGHTS BRIGHTNESS CONTROLLER
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LEFT BRAKE LIGHT/TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT LICENSE PLATE LIGHT
LT BLU WIRE
NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY)
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT LICENSE PLATE LIGHT
TAILLIGHT RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF RELAY CONTROL MODULE ENGINE COMPT)
USA: TECHNOLOGY PACKAGE, CMBS/PAX PACKAGE; CANADA: PREMIUM PACKAGE W/ BASE
WHT WIRE
WHT/BLU WIRE
WIPER/WASHER SWITCH COMBINATION SWITCH CONTROL UNIT
Go to component -> Instrument illumination circuit (1 of 3) -> LEFT FRONT PARKING LIGHT
Wiring diagram left front parking light (4 of 4)
A/T GEAR POSITION INDICATOR PANEL LIGHT
ACC CUT RELAY
BASE
BLU WIRE
BLU/WHT WIRE
CANADA
CANADA: PREMIUM PACKAGE
COIL POCKET LIGHT DASH LIGHTS CONSOLE BRIGHTNESS BOX CONTROLLER LIGHT
CONTROL BLOCK
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FROM FUSE 30 (DIAGRAM 3 OF 6)
FROM FUSE 32 (DIAGRAM 2 OF 6)
FROM IGNITION SWITCH (DIAGRAM 2 OF 6)
FROM LOW BEAM HEADLIGHT RELAY (DIAGRAM 3 OF 6)
FRONT PASSENGER'S SEAT VENTILATION SWITCH FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 4
FUSE 7
GLOVE BOX AUDIO LIGHT CLIMATE UNIT CONTROL J/C UNIT
GRN WIRE
GRY WIRE
IGNITION SWITCH CONTROL UNIT
J/C
LEFT FRONT PARKING LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR ROOF BRAKE INDIVIDUAL CONSOLE LIGHT/ MAP TAILLIGHT LIGHTS
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
NAVIGATION UNIT
PACKAGE) (CANADA: PREMIUM PACKAGE)
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RELAY
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT LICENSE PLATE LIGHT
TAILLIGHT RELAY
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) RELAY CONTROL MODULE
USA: TECHNOLOGY PACKAGE, CMBS/PAX PACKAGE;
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> LEFT FRONT PARKING LIGHT
