Acura RL II facelift (2008-2012) keyless driver's footwell access control light unit Wiring diagram
This page shows the only wiring diagram for the component.keyless driver's footwell access control light unit, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram keyless driver's footwell access control light unit (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
AUDIO HANDS- ACTIVE UNIT FREE- NOISE CANCELLATION LINK CONTROL UNIT UNIT
BLOWER MOTOR RELAY
CONTROL BLOCK
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FROM FUSE 12 (DIAGRAM 1 OF 6)
FROM FUSE 9 (DIAGRAM 2 OF 6)
FRONT SEAT HEATER RELAY
FUSE 15
FUSE 2
FUSE 30
FUSE 5
FUSE 6
FUSE 7
FUSE 8
GRN WIRE
HIGH BEAM HEADLIGHT RELAY
IN-CAR CLIMATE TEMPERATURE CONTROL SENSOR UNIT
J/C
KEYLESS DRIVER'S FOOTWELL ACCESS CONTROL LIGHT UNIT
LOW BEAM HEADLIGHT RELAY
MICU +B
NAVIGATION ACURA LINK UNIT CONTROL UNIT (XM RECEIVER)
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK PNK WIRE
PNK WIRE
REAR SEAT HEATER RELAY (CANADA) PASSENGER'S AUXILIARY UNDER-DASH RELAY BOX
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY (DIAGRAM 6 OF 6)
RELAY CONTROL MODULE
RIGHT REAR DOOR COURTESY FRONT LIGHT PASSENGER'S FOOTWELL LIGHT
TO FUSE 4 (DIAGRAM 6 OF 6)
TO FUSE 7 (DIAGRAM 5 OF 6)
TRUNK LIGHT B
TRUNK RIGHT RIGHT LIGHT A REAR REAR POWER DOOR WINDOW INNER SWITCH HANDLE LIGHT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
USA: TECHNOLOGY USA: BASE, PACKAGE, CMBS/ CANADA PAX PACKAGE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> KEYLESS DRIVER'S FOOTWELL ACCESS CONTROL LIGHT UNIT
