Acura RL II facelift (2008-2012) junction connector Wiring diagrams
This page contains all the electrical diagrams for the component. junction connector, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram junction connector (1 of 2)
BLK WIRE
BRN WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH (UNDER DRIVER'S SEAT)
DRIVER'S SEAT BELT TENSION REDUCER SOLENOID (ON BASE OF LEFT "B" PILLAR)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH (UNDER FRONT PASSENGER'S SEAT)
FUSE 21
GRN WIRE
HOT IN ON OR START
JUNCTION
JUNCTION CONNECTOR
LT GRN WIRE
ORG/ WIRE
RED WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
YEL WIRE
Go to component -> Passive restraints circuit -> JUNCTION CONNECTOR
Wiring diagram junction connector (2 of 2)
AUXILIARY UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
AUXILIARY UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 32
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
COMPT)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ELD UNIT
FUSE 31
IGNITION SWITCH
JUNCTION CONNECTOR
LOCK
LT BLU WIRE
LT GRN WIRE
MULTI- FUSE 22
MULTI- FUSE 23
PCM STRLD (UNDER MIDDLE OF DASH)
PNK WIRE
RED WIRE
STARTER
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STARTER MOTOR
STARTER SOLENOID
STRLY
STS
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE
WHT WIRE
Go to component -> Starting circuit -> JUNCTION CONNECTOR
