Acura RL II facelift (2008-2012) ignition key switch ignition switch control unit Wiring diagram
This page shows the only wiring diagram for the component.ignition key switch ignition switch control unit, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition key switch ignition switch control unit (1 of 1)
AS DOOR SW
BCAN SG 1
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT LEFT REAR POWER WINDOW SWITCH
CONTROL UNIT RIGHT REAR POWER WINDOW SWITCH
DOOR SW
DOOR SW KEY LOCK KEY UNLOCK
DRIVER'S DOOR
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
FRONT PASSENGER'S DOOR SWITCH
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
IGNITION KEY LIGHT
IGNITION KEY SWITCH IGNITION SWITCH CONTROL UNIT
J/C
KEY LOCK CYLINDER SWITCH
KEY LT-
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH (REAR OF LEFT REAR DOOR)
LT BLU WIRE
LT GRN WIRE
MICU VBU
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
RED WIRE
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR SWITCH KNOB SWITCH/ DOOR SWITCH (REAR OF RIGHT REAR DOOR)
SWITCH
UART
UNLOCK KEY
VBU
VBU CAN UART
WHT WIRE
Go to component -> Entry light timer circuit -> IGNITION KEY SWITCH IGNITION SWITCH CONTROL UNIT
