Acura RL II facelift (2008-2012) fuse 7 fuse 20 Wiring diagram
This page shows the only wiring diagram for the component.fuse 7 fuse 20, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 7 fuse 20 (1 of 1)
AUDIO SYSTEM
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FP-
FPC
FUSE 21
FUSE 7 FUSE 20
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PSP SWITCH (RIGHT SIDE OF ENGINE)
RED WIRE
RED/BLK WIRE
TOP OF TRANSMISSION)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.7l (4 of 6) -> FUSE 7 FUSE 20
