Acura RL II facelift (2008-2012) fuse 30 fuse/relay box Wiring diagram
This page shows the only wiring diagram for the component.fuse 30 fuse/relay box, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 30 fuse/relay box (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DRIVER'S SEAT HEATER SWITCH
DRIVER'S UNDER-DASH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT SEAT HEATER RELAY
FUSE 30 FUSE/RELAY BOX
FUSE 6
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
LO 5 3
LO HI
LT BLU WIRE
LT GRN WIRE
ON IND.
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
RED WIRE
SEAT CUSHION)
SEAT HEATER SWITCH LIGHT
SEAT HEATER SWITCH LIGHT 2 4 HI
SEAT-BACK DRIVER'S SEAT HEATER
WHT/BLU WIRE
YEL WIRE
Go to component -> Front heated seats circuit -> FUSE 30 FUSE/RELAY BOX
