Acura RL II facelift (2008-2012) front individual map lights Wiring diagram
This page shows the only wiring diagram for the component.front individual map lights, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front individual map lights (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
COURTESY
DOOR SW
DRIVER'S UNDER-DASH
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM
FRONT INDIVIDUAL MAP LIGHTS
FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
GRY WIRE
INN HANDLE ILL
INTERIOR LIGHT SWITCH (DOOR)
INTERIOR LIGHT SWITCH (OFF) INTERIOR LIGHT SWITCH (ON)
J/C
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT SWITCH
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
LEFT REAR DOOR SWITCH 1) DOOR OPEN
LEFT REAR POWER WINDOW SWITCH
LT BLU WIRE
PNK WIRE
RED WIRE
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT SWITCH
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
RIGHT REAR DOOR SWITCH 1) DOOR OPEN
RIGHT REAR POWER WINDOW SWITCH
ROOF CONSOLE
SGND
UART VBU
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> FRONT INDIVIDUAL MAP LIGHTS
