Acura RL II facelift (2008-2012) front active noise cance- llation microphone Wiring diagram
This page shows the only wiring diagram for the component.front active noise cance- llation microphone, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front active noise cance- llation microphone (1 of 1)
ACTIVE NOISE CANCE- LLATION UNIT
ACURALINK CONTROL UNIT (USA: TECHNOLOGY PACKAGES CMBS/ PAX PACKAGE)
BLK WIRE
CANCE- LLATION MICROPHONE
CENTER REAR HEADREST ACTUATOR
FRONT ACTIVE NOISE CANCE- LLATION MICROPHONE
FRONT PASSENGER'S LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER (W/ BASE)
FRONT PASSENGER'S SEAT HEATER SWITCH (W/ BASE)
FUEL FILL DOOR OPENER SOLENOID
HANDS FREE LINK CONTROL UNIT
J/C
LEFT BACKUP LIGHT
LEFT REAR HEADREST ACTUATOR
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT HEATER (CANADA)
LEFT RIGHT LICENSE PLATE LIGHT LICENSE PLATE LIGHT
NAVIGATION DISPLAY UNIT
NAVIGATION UNIT
ODS UNIT
POWER REAR WINDOW SUNSHADE CONTROL UNIT
REAR ACTIVE NOISE
RIGHT BACKUP LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
RIGHT REAR HEADREST ACTUATOR
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH (NOT USED)
RIGHT REAR SEAT BACK HEATER
RIGHT REAR SEAT HEATER (CANADA)
SH-AWD CONTROL UNIT
SH-AWD RELAY
STEREO AMPLIFIER
TPMS CONTROL UNIT
TRUNK LID OUTER HANDLE SWITCH
Go to component -> Ground distribution circuit (5 of 5) -> FRONT ACTIVE NOISE CANCE- LLATION MICROPHONE
