Acura RL II facelift (2008-2012) fm signal sub-window antenna Wiring diagrams

This page contains all the electrical diagrams for the component. fm signal sub-window antenna, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram fm signal sub-window antenna (1 of 4)

Wiring diagram fm signal sub-window antenna for Acura RL II facelift (2008-2012) (1 of 4)

Get access

1 2 3 4 5 6 AUX DET AUX GND AUX R-CH AUX SIG GND AUX L-CH AUX SH GND 1 2 3 4 5 SIG SH (AM/FM) SIG SH (AM/FM) SWD +B AM/FM MAIN ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR) AM/FM SUB-ANTENNA AMPLIFIER ANTENNA SUB-LEAD CONNECTOR (BEHIND RIGHT KICK PANEL) AUDIO R- AUDIO L- AUDIO UNIT AUX DET AUX GND AUX L CH AUX R CH AUX SIG GND AUXILIARY JACK ASSEMBLY BLK WIRE FM SIGNAL MAIN WINDOW ANTENNA FM SIGNAL SUB-WINDOW ANTENNA GA-NET BUS+ GA-NET BUS- GND GRN WIRE GRY WIRE J/C NCA WIRE PPL PPL 28 29 REAR WINDOW AM SIGNAL MAIN WINDOW ANTENNA RED WIRE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except usa (5 of 7) -> FM SIGNAL SUB-WINDOW ANTENNA

Wiring diagram fm signal sub-window antenna (2 of 4)

Wiring diagram fm signal sub-window antenna for Acura RL II facelift (2008-2012) (2 of 4)

Get access

+B SYS ON GA-NET-BUS SH AUDIO SH AUDIO R+ AUDIO L+ PPL 1 2 ALX DET AUX GND 3 4 5 AUX SIG GND AUX L CH AUX R-CH AM SIGNAL MAIN WINDOW ANTENNA AM/FM MAIN ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR) AM/FM SUB-ANTENNA AMPLIFIER ANTENNA SUB-LEAD LEAD CONNECTOR (BEHIND RIGHT KICK PANEL) AUDIO UNIT AUXILIARY JACK ASSEMBLY BLK WIRE FM SIGNAL MAIN WINDOW ANTENNA FM SIGNAL SUB-WINDOW ANTENNA GA-NET BUS+ GA-NET BUS- GND GRN WIRE GRY WIRE J/C NCA WIRE PPL REAR WINDOW RED WIRE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, usa (5 of 7) -> FM SIGNAL SUB-WINDOW ANTENNA
