Acura RL II facelift (2008-2012) computer data lines system can-h sh ecu bus ecu bus+ Wiring diagrams

This page contains all the electrical diagrams for the component. computer data lines system can-h sh ecu bus ecu bus+, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram computer data lines system can-h sh ecu bus ecu bus+ (1 of 4)

Wiring diagram computer data lines system can-h sh ecu bus ecu bus+ for Acura RL II facelift (2008-2012) (1 of 4)

Get access

1 2 3 4 5 6 7 8 +B PPL 2 1 NAVIGATION SERVICE CHECK CONNECTOR (UNDER NAVIGATION UNIT) AIR CONDITIONING SYSTEM AUDIO L+ AUDIO R- AUDIO SH B SIG 1 C SIG 1 GND SIG 1 AC SO AC CLK BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CAN-H SH ECU BUS ECU BUS+ GA-NET BUS SH GA-NET BUS- GND BACK LT VSP DIAG + DIAG - GRN WIRE GRY WIRE INPUT JOG CAN-L SH JOG ECU BUS- COMPUTER DATA LINES SYSTEM NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY) NCA WIRE ORG/ WIRE PPL PPL AIR CONDITIONING SYSTEM RED WIRE VSS OUT PPL WHT WIRE XM ANTENNA XM RECEIVER (LEFT SIDE OF TRUNK) YEL WIRE

Go to component -> Navigation circuit, except usa (4 of 7) -> COMPUTER DATA LINES SYSTEM CAN-H SH ECU BUS ECU BUS+

Wiring diagram computer data lines system can-h sh ecu bus ecu bus+ (2 of 4)

Wiring diagram computer data lines system can-h sh ecu bus ecu bus+ for Acura RL II facelift (2008-2012) (2 of 4)

Get access

+B PPL 2 1 DIAG+ DIAG- (UNDER NAVIGATION UNIT) ACURALINK CONTROL UNIT (XM RECEIVER) (EXCEPT BASE) (ON LEFT SIDE OF TRUNK) ACURALINK REPROGRAMMING CONNECTOR AIR CONDITIONING SYSTEM AUDIO L+ AUDIO R- B SIG 1 C SIG 1 GND SIG 1 AC SO AC CLK B-CAN BACK LT- BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CAN-H SH ECU BUS ECU BUS+ F-CAN H F-CAN L GA-NET BUS- GND BACK LT GRN WIRE GRY WIRE HFL COMM SH HFT COM 1 JOG CAN-L SH JOG ECU BUS- COMPUTER DATA LINES SYSTEM LINE OUT + LT GRN WIRE NAVI COMM SH NAVIGATION SERVICE CHECK CONNECTOR NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY) NCA WIRE ORG/ WIRE PCM VSS (UNDER OUT MIDDLE OF DASH) PPL PPL AIR CONDITIONING SYSTEM PPL PPL R SIG 1 G SIG 1 SH SIG 1 AC SI ILL + RED WIRE SUPPLEMENTAL RESTRAINTS SYSTEM WHT WIRE XM ANTENNA YEL WIRE

Go to component -> Navigation circuit, usa (4 of 7) -> COMPUTER DATA LINES SYSTEM CAN-H SH ECU BUS ECU BUS+
