Acura RL II facelift (2008-2012) coil pocket light dash lights console brightness box controller light Wiring diagram
This page shows the only wiring diagram for the component.coil pocket light dash lights console brightness box controller light, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coil pocket light dash lights console brightness box controller light (1 of 1)
A/T GEAR POSITION INDICATOR PANEL LIGHT
ACC CUT RELAY
BASE
BLU WIRE
BLU/WHT WIRE
CANADA
CANADA: PREMIUM PACKAGE
COIL POCKET LIGHT DASH LIGHTS CONSOLE BRIGHTNESS BOX CONTROLLER LIGHT
CONTROL BLOCK
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FROM FUSE 30 (DIAGRAM 3 OF 6)
FROM FUSE 32 (DIAGRAM 2 OF 6)
FROM IGNITION SWITCH (DIAGRAM 2 OF 6)
FROM LOW BEAM HEADLIGHT RELAY (DIAGRAM 3 OF 6)
FRONT PASSENGER'S SEAT VENTILATION SWITCH FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 4
FUSE 7
GLOVE BOX AUDIO LIGHT CLIMATE UNIT CONTROL J/C UNIT
GRN WIRE
GRY WIRE
IGNITION SWITCH CONTROL UNIT
J/C
LEFT FRONT PARKING LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR ROOF BRAKE INDIVIDUAL CONSOLE LIGHT/ MAP TAILLIGHT LIGHTS
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
NAVIGATION UNIT
PACKAGE) (CANADA: PREMIUM PACKAGE)
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PCM
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RELAY
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT LICENSE PLATE LIGHT
TAILLIGHT RELAY
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) RELAY CONTROL MODULE
USA: TECHNOLOGY PACKAGE, CMBS/PAX PACKAGE;
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> COIL POCKET LIGHT DASH LIGHTS CONSOLE BRIGHTNESS BOX CONTROLLER LIGHT
