Acura RL II facelift (2008-2012) camera sh Wiring diagrams
This page contains all the electrical diagrams for the component. camera sh, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram camera sh (1 of 3)
1 2 3 4 5 USB VBUS USB DATA- USB DATA+ USB GND USB SH
AMPLIFIER
AUDIO R- AUDIO L-
BLK WIRE
CAMERA ADPT
CAMERA GND
CAMERA SH
CAMERA V +
GA-NET BUS+ GA-NET BUS- GND
GPS ANTENNA (MIDDLE OF REAR SHELF)
GRN WIRE
GRY WIRE
HFL COMM SH
J/C
MIC SIG
NAVIGATION SYSTEM
NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY)
NCA WIRE
PPL
PPL 28 29
RC GND
RC VCC
RED WIRE
RGL +
RGL GND
RGL SH
SH (GPS)
SH MIC
SIG (GPS)
STRG SW
USB
USB ADAPTER UNIT
USB DATA -
USB GND
USB JACK
USB SH
USB VBUS
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, except usa (6 of 7) -> CAMERA SH
Wiring diagram camera sh (2 of 3)
1 2 3 4 5 USB VBUS USB DATA- USB DATA+ USB GND USB SH
AMPLIFIER
AUDIO R- AUDIO L-
BLK WIRE
CAMERA ADPT
CAMERA GND
CAMERA SH
CAMERA V +
GA-NET BUS+ GA-NET BUS- GND
GPS ANTENNA (MIDDLE OF REAR SHELF)
GRN WIRE
GRY WIRE
HFL COMM SH
J/C
MIC SIG
NAVIGATION SYSTEM
NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY)
NCA WIRE
PPL
PPL 28 29
RC GND
RC VCC
RED WIRE
RGL +
RGL GND
RGL SH
SH (GPS)
SH MIC
SIG (GPS)
STRG SW
USB
USB ADAPTER UNIT
USB DATA -
USB GND
USB JACK
USB SH
USB VBUS
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, except usa (6 of 7) -> CAMERA SH
Wiring diagram camera sh (3 of 3)
B SIG 1
BACK LT-
BLK WIRE
BLU WIRE
BRN WIRE
C SIG 1
CAMERA ADPT
CAMERA GND
CAMERA SH
CAMERA V +
DRIVER'S
G SIG 1
GND SIG 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE 5
HOT AT ALL TIMES FUSE 7 UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
NAVIGATION DISPLAY UNIT
NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY)
R SIG 1
RC GND
RC VCC
REARVIEW CAMERA (MIDDLE OF TRUNK LID)
RED WIRE
SH SIG 1
USA: TECHNOLOGY PACKAGE, CMBS/PAX CANADA PACKAGE
WHT WIRE
YEL WIRE
Go to component -> Rear camera circuit -> CAMERA SH
