Acura RL II facelift (2008-2012) backup sensor control unit connector Wiring diagram
This page shows the only wiring diagram for the component.backup sensor control unit connector, which is found in the car Acura RL II facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup sensor control unit connector (1 of 1)
ATP-R
BACKUP SENSOR BEEPER ASSEMBLY
BACKUP SENSOR BEEPER CONNECTOR
BACKUP SENSOR CONTROL UNIT (RIGHT SIDE OF TRUNK)
BACKUP SENSOR CONTROL UNIT CONNECTOR
BACKUP SENSOR IN LINE FUSE
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ENGINE CONTROLS SYSTEM PPL
FUSE 21
GRN WIRE
HOT IN ON OR START
LEFT BACKUP LIGHT
LEFT CORNER BACKUP SENSOR
LEFT MIDDLE BACKUP SENSOR
MICU BACK LT
NCA WIRE
ORG/ WIRE
ORG/RED WIRE
PPL
RED WIRE
RIGHT BACKUP LIGHT
RIGHT CORNER BACKUP SENSOR
RIGHT MIDDLE BACKUP SENSOR
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Parking assistant circuit -> BACKUP SENSOR CONTROL UNIT CONNECTOR
