Acura RL II facelift (2008-2012) b-can ig key sw Wiring diagrams
This page contains all the electrical diagrams for the component. b-can ig key sw, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
b-can ig key sw wiring diagram (1 of 2)
5 23 22 9 +B DOOR LOCK VBU
B-CAN IG KEY SW
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRAKE SYSTEM INDICATOR
BRN WIRE
DR UN L
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 32
FUSE 7 FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IMMOBILIZER SYSTEM INDICATOR
J/C
J/C, CUT (BASE OF RELAY LEFT "B" PILLAR)
KEYLESS ACCESS SYSTEM INDICATOR
KEYLESS ANSWER BACK BUZZER (BEHIND MIDDLE OF REAR BUMPER)
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NOT USED NOT USED
ORG/ WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
PPL PNK WIRE
RED WIRE
SEATS SYSTEM
SECURITY INDICATOR BLINKING CIRCUIT SECURITY INDICATOR
SHIFT INTERLOCK SYSTEM AUXILIARY UNDER-DASH RELAY BOX (UNDER LEFT SIDE OF DASH)
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
STARTING/CHARGING SYSTEM
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
TRANSMISSIONS SYSTEM
TRUNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
TRUNK HNDL SW
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UN L
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 5) -> B-CAN IG KEY SW
b-can ig key sw wiring diagram (2 of 2)
5 23 22 9 +B DOOR LOCK VBU
B-CAN IG KEY SW
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRAKE SYSTEM INDICATOR
BRN WIRE
DR UN L
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 32
FUSE 7 FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IMMOBILIZER SYSTEM INDICATOR
J/C
J/C, CUT (BASE OF RELAY LEFT "B" PILLAR)
KEYLESS ACCESS SYSTEM INDICATOR
KEYLESS ANSWER BACK BUZZER (BEHIND MIDDLE OF REAR BUMPER)
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NOT USED NOT USED
ORG/ WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
PPL PNK WIRE
RED WIRE
SEATS SYSTEM
SECURITY INDICATOR BLINKING CIRCUIT SECURITY INDICATOR
SHIFT INTERLOCK SYSTEM AUXILIARY UNDER-DASH RELAY BOX (UNDER LEFT SIDE OF DASH)
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
STARTING/CHARGING SYSTEM
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
TRANSMISSIONS SYSTEM
TRUNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
TRUNK HNDL SW
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UN L
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 5) -> B-CAN IG KEY SW
