Acura RL II facelift (2008-2012) active noise control circuit pnk Wiring diagrams
This page contains all the electrical diagrams for the component. active noise control circuit pnk, in which he is found in the car Acura RL II facelift (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram active noise control circuit pnk (1 of 2)
ACTIVE NOISE CONTROL CIRCUIT PNK WIRE
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CTR SP + FL SP+
DRIVER'S DOOR SPEAKER
FRONT CENTER SPEAKER (+)
FRONT PASSENGER'S DOOR SPEAKER
FUSE 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR DOOR SPEAKER
LEFT REAR TWIDDLER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
OF TRUNK)
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK CTR SP - FL SP- WIRE
PNK WIRE
PPL
RADIO SW +B
RED WIRE
RG-L + RG-L GND MIC R IN - MIC R IN +
RIGHT REAR DOOR SPEAKER
RIGHT REAR TWIDDLER
RIGHT TWEETER
STEREO AMPLIFIER (RIGHT SIDE
SUBWOOFER
TELM SIG+ TELM SIG- F + F - R + R -
WHT WIRE
Go to component -> Navigation circuit, except usa (7 of 7) -> ACTIVE NOISE CONTROL CIRCUIT PNK WIRE
