Acura RL II facelift (2008-2012) 2 13 uart door sw Wiring diagram

2 13 UART DOOR SW B-CAN BASE BLK WIRE BLU/YEL WIRE BRAKE FLUID LEVEL SWITCH (INTEGRAL TO BRAKE FLUID RESERVOIR CAP) CABLE REEL (CONNECTOR B: ON STEERING COLUMN) (CONNECTOR C: ON STEERING WHEEL) CAN L CAN UART DR DOOR SW COMPUTER DATA LINES SYSTEM CONTROL BLOCK CPSW DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH DRIVER'S DOOR SWITCH DRIVER'S MPCS UNIT DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) EXCEPT BASE FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH/DOOR SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S MPCS UNIT FUEL TANK UNIT FUEL (UNDER GAUGE LEFT SIDE OF SENDING REAR SEAT) UNIT FUSE 21 FUSE 7 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER CONTROL UNIT- RECEIVER (ON RIGHT SIDE OF STEERING COLUMN) KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH) LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH (REAR OF LEFT REAR DOOR) LEFT REAR DOOR SWITCH LEFT REAR POWER WINDOW SWITCH LT BLU WIRE LT GRN WIRE MICU NEXT SWITCH OIL PRESSURE SWITCH ORG/ WIRE PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH) PCM (UNDER MIDDLE OF DASH) PNK WIRE PREVIOUS SWITCH RED WIRE RELAY CONTROL MODULE RIGHT REAR DOOR SWITCH RIGHT REAR POWER WINDOW SWITCH SECONDARY FUEL GAUGE SENDING UNIT (UNDER RIGHT SIDE OF REAR SEAT) SELECT/ RESET SWITCH SELECT/RESET INFORMATION SWITCH STEERING WHEEL) UART AS DOOR SW UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE YEL/RED WIRE
