Fuel door release circuit for Acura RL II (2004-2008)
Fuel door release circuit
B-CAN
BLK WIRE
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR) VMP
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUEL FILL DOOR OPENER RELAY
FUEL FILL DOOR OPENER SOLENOID (ON LEFT SIDE OF TRUNK)
FUEL FILL DOOR OPENER SWITCH
FUEL LID
FUEL SW
FUSE 21
FUSE 27
FUSE 7
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MICU
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
TRUNK LID OPENER/FUEL FILL DOOR OPENER SWITCH
VBU
WHT WIRE
YEL WIRE
