Rear window sun shade circuit for Acura RL II (2004-2008)

Rear window sun shade circuit

Get access

1 2 3 4 5 GN ATP-R BACK LT- BLK WIRE BLU WIRE BRN WIRE CONTROL UNIT) DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FUSE 11 FUSE 21 GRN WIRE GRY WIRE HOT IN ON OR START MICU PCM (UNDER MIDDLE OF DASH) POWER REAR WINDOW SUNSHADE CONTROL UNIT (MIDDLE OF REAR SHELF) POWER REAR WINDOW SUNSHADE MOTOR (MIDDLE OF REAR SHELF) POWER REAR WINDOW SUNSHADE SWITCH PPL ROOF CONSOLE SW BACK LT TRANSMISSION RANGE SWITCH WHT WIRE
