Instrument illumination circuit for Acura RL II (2004-2008)
Instrument illumination circuit (1 of 3)
BLK WIRE
BLK/RED WIRE
BRIGHTENING SWITCH
CANADA
COMBINATION LIGHT SWITCH
CONTROL BLOCK
DASH LIGHTS BRIGHTNESS CONTROLLER
DIMMING SWITCH
DRIVER'S SEAT VENTILATION CONTROL UNIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD
HOT AT ALL TIMES
HOT IN ON OR START
ILL
LEFT REAR DOOR ASHTRAY LIGHT
LT BLU WIRE
NAVIGATION ILL(+) UNIT (IN TRUNK, BELOW LEFT GND SIDE OF PACKAGE TRAY)
ORG/ WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RED/BLK WIRE
TAILLIGHT RELAY
UNDER-HOOD FUSE/RELAY RELAY BOX CONTROL (LEFT REAR OF MODULE ENGINE COMPT)
WHT WIRE
WIPER/ WASHER SWITCH COMBINATION SWITCH CONTROL UNIT
Instrument illumination circuit (2 of 3)
2/-
A/T GEAR POSITION CONSOLE LIGHT
AFS OFF/ VSA OFF/ CMBS OFF/ SWITCH
AMBIENT LIGHTS (2)
AUDIO UNIT
BLK WIRE
BLK/BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CABLE REEL (ON STEERING COLUMN)
CONSOLE LIGHT
COURTESY LIGHTS CIRCUIT
CRUISE CONTROL COMBINATION SWITCH
DRIVER'S SEAT HEATER SWITCH (USA)
DRIVER'S SEAT HEATER SWITCH LIGHT
FRONT INDIVIDUAL MAP LIGHTS
GRN WIRE
GRY WIRE
HFL SWITCH
INFORMATION SWITCH
LT BLU WIRE
LT GRN WIRE
MOONROOF SWITCH
ORG/ WIRE
ORG/WHT WIRE
POWER MIRROR SWITCH
RADIO REMOTE
REAR INDIVIDUAL MAP LIGHTS
RED WIRE
ROOF CONSOLE
SELECT/ RESET
STEERING WHEEL)
SWITCH
SWITCH LIGHTS (2)
VOICE CONTROL
YEL/RED WIRE
Instrument illumination circuit (3 of 3)
BLK WIRE
CANADA
CLIMATE CONTROL UNIT
COIN POCKET LIGHT
DISPLAY PANEL CONTROL UNIT
DRIVER'S SEAT VENTILATION SWITCH (CANADA)
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT VENTILATION CONTROL UNIT ILL(+)
FRONT PASSENGER'S SEAT VENTILATION SWITCH (CANADA)
FUSE 9
GLOVE BOX LIGHT
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
LT BLU WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
RED WIRE
RIGHT REAR DOOR ASHTRAY LIGHT SWITCH
