Adaptive front lighting circuit for Acura RL II (2004-2008)

Adaptive front lighting circuit (1 of 3)

RL Acura II (2004-2008): Adaptive front lighting circuit (1 of 3)

Get access

AFS INDICATOR ATP-R AUTO LT SIP AUTO LT SIO AUTO LT SIG B-CAN AUTOMATIC LIGHTING SENSOR/SUNLIGHT SENSOR (FRONT CENTER OF DASH) BLK WIRE BLK/RED WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT COMPUTER DATA LINES SYSTEM DRIVER'S UNDER-DASH FUSE/RELAY BOX FUSE 11 FUSE 21 FUSE 29 FUSE 7 GAUGE CONTROL MODULE GRN WIRE HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE MICU PCM (UNDER MIDDLE OF DASH) PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER PPL RED WIRE RED/BLK WIRE TRANSMISSION RANGE SWITCH W/ W/O TECHNOLOGY TECHNOLOGY PACKAGE PACKAGE WARNING DRIVE CIRCUIT WHT WIRE WIPER/ WASHER SWITCH WIPER/WASHER SYSTEM

Adaptive front lighting circuit (2 of 3)

RL Acura II (2004-2008): Adaptive front lighting circuit (2 of 3)

Get access

33 35 43 28 29 41 9 S GND SVCC STR B STR A STR D RRP RLP PNK WIRE BLK WIRE BLU WIRE BRN WIRE GRN WIRE LT GRN WIRE ORG/ WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PNK WIRE PPL PPL STG B STG A STG C S GND STEERING ANGLE SENSOR SVCC S GND STR A STR B STR-D SVCC YAW RATE-LATERAL ACCELERATION SENSOR (UNDER CENTER CONSOLE) YEL WIRE

Adaptive front lighting circuit (3 of 3)

RL Acura II (2004-2008): Adaptive front lighting circuit (3 of 3)

Get access

ADAPTIVE FRONT LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH) AFS SWITCH 1) PRESSED AG HSG HSV RHSS PNK WIRE BLK WIRE BLU WIRE BRN WIRE CONTROL BLOCK GRN WIRE GRY WIRE HALL SENSOR HEADLIGHT LEVELING SENSOR (UNDER LEFT REAR OF VEHICLE) LEFT ADAPTIVE FRONT LIGHTING GEARBOX (BEHIND LEFT HEADLIGHT ASSEMBLY) LEFT HEADLIGHT LEVELING MOTOR LHSS SSR B-CAN SSR STZ STA PPL LT BLU WIRE LT GRN WIRE PNK AS SV STB WIRE PNK WIRE PPL PPL AFS OFF SW SCS PPL PNK WIRE RED WIRE RELAY CONTROL MODULE RIGHT ADAPTIVE FRONT LIGHTING GEARBOX (BEHIND RIGHT HEADLIGHT ASSEMBLY) RIGHT HEADLIGHT LEVELING MOTOR RLP RRP STEPPER MOTOR UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE YEL WIRE
