Acura RL II (2004-2008) Electronic power steering circuit

1 2 3 4 5 6 7 8 9 10 11 12 VSS COM PPL BLK WIRE BLU WIRE BRN WIRE DRIVE CIRCUIT DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) ECPS CONTROL UNIT (UNDER LEFT SIDE OF DASH) ECPS INDICATOR ECPS VALVE (LEFT SIDE OF ENGINE COMPT) FUSE 21 FUSE 7 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START J/C LT BLU WIRE LT GRN WIRE MB MA NEP MB-R MA-R PCM (UNDER MIDDLE OF DASH) PNK NEP VSSOUT WIRE PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER PPL RED WIRE WHT WIRE WLP GROUND YEL WIRE
