Acura RL II (2004-2008) Data link connector circuit

7 8 DIAG (P) DIAG (N) ADAPTIVE FRONT LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRN (OR BLU) WIRE BRN WIRE CONTROL UNIT (BEHIND RIGHT SIDE OF GLOVE BOX) DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH) DLC DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) MICU FUSE 8 GRN WIRE GRY WIRE HOT AT ALL TIMES IMMOBILIZER CONTROL UNIT- RECEIVER (ON RIGHT SIDE OF STEERING COLUMN) K LINE KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH) LT BLU WIRE LT GRN (OR BLU) WIRE LT GRN WIRE MES CONNECTOR MES K-LINE SCS NAVIGATION SERVICE CHECK CONNECTOR (UNDER NAVIGATION UNIT) NAVIGATION UNIT (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY) PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PCM (BEHIND CENTER OF DASH) RED (OR BLU) WIRE RED WIRE SCS SH-AWD CONTROL UNIT (BEHIND RIGHT SEAT) SRS UNIT (UNDER LOWER MIDDLE OF DASH) TPMS RECEIVER UNIT (RIGHT SIDE OF REAR SHELF) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) VSA MODULATOR CONTROL UNIT (ON RIGHT SIDE OF ENGINE COMPT) WEN WHT WIRE YEL WIRE
