Wiring diagram trunk, tailgate, fuel doors system trnk act trunk switch keyless buzzer atpp cds (1 of 2)
5 23 22 9 +B DOOR LOCK VBU
AUXILIARY UNDER-DASH RELAY BOX (UNDER LEFT SIDE OF DASH)
B-CAN IG KEY SW
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
DR UN L
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 32
FUSE 7 FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IMMOBILIZER SYSTEM INDICATOR
J/C
KEYLESS ACCESS SYSTEM INDICATOR
KEYLESS ANSWER BACK BUZZER (BEHIND MIDDLE OF REAR BUMPER)
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NOT USED NOT USED
ONSTAR CONTROL UNIT (BEHIND REAR SEAT)
PNK PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
PPL PNK WIRE
RED WIRE
RELAY
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
SECURITY INDICATOR
SECURITY INDICATOR BLINKING CIRCUIT
SHIFT INTERLOCK SYSTEM
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
STARTING/CHARGING SYSTEM
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
TRNK HNDL SW
TRUNK, TAILGATE, FUEL DOORS SYSTEM TRNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
UN L
USA
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 5) -> TRUNK, TAILGATE, FUEL DOORS SYSTEM TRNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
Wiring diagram trunk, tailgate, fuel doors system trnk act trunk switch keyless buzzer atpp cds (2 of 2)
5 23 22 9 +B DOOR LOCK VBU
AUXILIARY UNDER-DASH RELAY BOX (UNDER LEFT SIDE OF DASH)
B-CAN IG KEY SW
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
DR UN L
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE 21
FUSE 32
FUSE 7 FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IMMOBILIZER SYSTEM INDICATOR
J/C
KEYLESS ACCESS SYSTEM INDICATOR
KEYLESS ANSWER BACK BUZZER (BEHIND MIDDLE OF REAR BUMPER)
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NOT USED NOT USED
ONSTAR CONTROL UNIT (BEHIND REAR SEAT)
PNK PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
PPL PNK WIRE
RED WIRE
RELAY
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
SECURITY INDICATOR
SECURITY INDICATOR BLINKING CIRCUIT
SHIFT INTERLOCK SYSTEM
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
STARTING/CHARGING SYSTEM
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
TRNK HNDL SW
TRUNK, TAILGATE, FUEL DOORS SYSTEM TRNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
UN L
USA
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 5) -> TRUNK, TAILGATE, FUEL DOORS SYSTEM TRNK ACT TRUNK SWITCH KEYLESS BUZZER ATPP CDS
