Acura RL II (2004-2008) trunk left right lid outer handle switch license plate light license plate light Wiring diagram
This page shows the only wiring diagram for the component.trunk left right lid outer handle switch license plate light license plate light, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk left right lid outer handle switch license plate light license plate light (1 of 1)
ACTIVE NOISE CONTROL UNIT
ACURALINK CONNECTOR
ACURALINK CONTROL UNIT (XM RECEIVER)
AUDIO AMPLIFIER
BLK WIRE
DISPLAY PANEL CONTROL UNIT
FRONT ACTIVE NOISE CONTROL MICROPHONE
FRONT PASSENGER'S LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BACK FAN MOTOR (CANADA)
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT HEATER (USA)
FRONT PASSENGER'S SEAT VENTILATION CONTROL UNIT (CANADA)
FUEL FILL DOOR OPENER SOLENOID
FUEL PUMP CONTROL MODULE
HANDS FREE LINK CONTROL UNIT
J/C
LEFT "C" PILLAR)
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
LEFT REAR HEADREST ACTUATOR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
NAVIGATION UNIT
NOISE REDUCTION CONDENSER
ONSTAR CONTROL UNIT
OPDS UNIT
POWER REAR WINDOW SUNSHADE CONTROL UNIT
REAR ACTIVE NOISE CONTROL MICROPHONE
RIGHT CENTER HEADREST ACTUATOR
RIGHT REAR DOOR ASHTRAY LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
RIGHT REAR HEADREST ACTUATOR
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SEAT WEIGHT SENSOR UNIT
SH-AWD SH-AWD CONTROL RELAY UNIT
TPMS RECEIVER UNIT WINDOW MOTOR
TRUNK LEFT RIGHT LID OUTER HANDLE SWITCH LICENSE PLATE LIGHT LICENSE PLATE LIGHT
Go to component -> Ground distribution circuit (4 of 4) -> TRUNK LEFT RIGHT LID OUTER HANDLE SWITCH LICENSE PLATE LIGHT LICENSE PLATE LIGHT
