Acura RL II (2004-2008) tisa tesa Wiring diagram
This page shows the only wiring diagram for the component.tisa tesa, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tisa tesa (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VBU SVCC PNK WIRE
1 2 3 4 5 6 7 8 GND
3 2 PNK WIRE
5 13 6 11 10 25 2 4 7 RSEV SVCC RSEH RMH RMV RMC VBU UART SG PNK WIRE
7 5 6 8 PNK WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
FUSE 21
FUSE 25
FUSE 26
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
LEFT/RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
LT PPL
ORG/ WIRE
PNK J/C WIRE
PNK TEM + ETS TM - ETS TM + ETS WIRE
PNK WIRE
POWER TELESCOPING STEERING MOTOR/ POSITION SENSOR
POWER TILT STEERING MOTOR/ POSITION SENSOR
POWER TILT/ TELESCOPING STEERING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
POWER TILT/ TELESCOPING STEERING SWITCH
PPL
RED WIRE
RIGHT POWER MIRROR
SWBAT SEG
SWG UART TISB TESB
SWING
TELESCOPIC SWITCH
TEM - ETS
TILT
TILT SWITCH
TISA TESA
UP/DOWN MOTOR
WHT WIRE
YEL (OR PNK) WIRE
YEL WIRE
Go to component -> Memory systems circuit (3 of 4) -> TISA TESA
