Acura RL II (2004-2008) steering angle sensor svcc s gnd Wiring diagram
This page shows the only wiring diagram for the component.steering angle sensor svcc s gnd, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering angle sensor svcc s gnd (1 of 1)
33 35 43 28 29 41 9 S GND SVCC STR B STR A STR D RRP RLP PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
PPL
PPL STG B STG A STG C
S GND
STEERING ANGLE SENSOR SVCC S GND
STR A STR B
STR-D
SVCC
YAW RATE-LATERAL ACCELERATION SENSOR (UNDER CENTER CONSOLE)
YEL WIRE
Go to component -> Adaptive front lighting circuit (2 of 3) -> STEERING ANGLE SENSOR SVCC S GND
