Acura RL II (2004-2008) srs ind ind ctrl diag line ods lfs- rfs- ign in ign in Wiring diagram

BLK (OR BLU) WIRE BLK WIRE BLU WIRE BRN (OR BLU) WIRE BRN WIRE BUCK- LED BUCK- LED UN- BUCK- LED CABLE REEL CDS GNDA GNDB K-LINE DRIVER'S AIR BAG FIRST INFLATOR DRIVER'S AIR BAG SECOND INFLATOR DRIVER'S SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) DRIVER'S SEAT BELT TENSION REDUCER SOLENOID (BASE OF LEFT "B" PILLAR) DRIVER'S SEAT BELT TENSIONER (BASE OF LEFT "B" PILLAR) DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FRONT PASSENGER'S SEAT BELT SWITCH (IN FRONT PASSENGER'S SEAT BELT BUCKLE) FRONT PASSENGER'S SEAT BELT TENSION REDUCER SOLENOID (BASE OF LEFT "B" PILLAR) FRONT PASSENGER'S SEAT BELT TENSIONER (BASE OF RIGHT "B" PILLAR) FUSE 10 FUSE 21 FUSE 22 GRN (OR BLU) WIRE GRN (OR BRN) WIRE GRN WIRE GRY (OR BLU) WIRE HOT IN ON OR START J/C LBSC LBSD LFS+ RFS+ LRP+ LRP- RRP+ RRP- SS- SS+ LT BLU (OR BLU) WIRE LT BLU WIRE LT GRN (OR BLU) WIRE LT GRN WIRE MES CONN CHECK IN ORG (OR BLU) WIRE ORG/ WIRE PNK 1 2 3 4 5 6 7 WIRE PNK PNK PNK WIRE PNK PNK WIRE POWER SEATS SYSTEM (CANADA) RBSC RBSD RED (OR BLU) WIRE RED WIRE RED/WHT WIRE SRS IND IND CTRL DIAG LINE ODS LFS- RFS- IGN IN IGN IN SRS UNIT (UNDER LOWER MIDDLE OF DASH) STEERING WHEEL) TIRE PRESSURE MONITORING SYSTEM UN- BUCK- LED VIO (OR BLU) WIRE WHT WIRE YEL (OR BLU) WIRE YEL WIRE YEL/GRN WIRE
