Acura RL II (2004-2008) right middle back-up sensor Wiring diagram
This page shows the only wiring diagram for the component.right middle back-up sensor, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right middle back-up sensor (1 of 1)
ATP-R
BACK LT-
BACK-UP SENSOR BEEPER ASSEMBLY
BACK-UP SENSOR CONTROL UNIT
BACK-UP SENSOR IN-LINE FUSE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
GRY/RED WIRE
LEFT CORNER BACK-UP SENSOR
LEFT MIDDLE BACK-UP SENSOR
MICU
ORG/ WIRE
ORG/RED WIRE
PPL
RED WIRE
RIGHT BRAKE LIGHT/TAILLIGHT
RIGHT CORNER BACK-UP SENSOR
RIGHT MIDDLE BACK-UP SENSOR
TRANSMISSION RANGE SWITCH
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Parking assistant circuit -> RIGHT MIDDLE BACK-UP SENSOR
