Acura RL II (2004-2008) press fl Wiring diagram
This page shows the only wiring diagram for the component.press fl, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram press fl (1 of 1)
2/-
ACC CONTROL UNIT (BEHIND RIGHT SIDE OF GLOVE BOX)
AFS OFF/VSA OFF/CMBS OFF SWITCH (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRK DIAG
BRK LAMP
BRN WIRE
CMBS SWITCH
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
GND MR/TRX
GRN WIRE
GRY WIRE
J/C
K LINE
LEFT FRONT PRESSURE SENSOR (LEFT SIDE OF ENGINE COMPT)
LOGIC GND 1
LOGIC GND 2
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR (BEHIND FRONT GRILLE)
MR/TRX
PNK WIRE
POWER GND
PPL
PRESS FL
PRESS FR
RED WIRE
RIGHT FRONT PRESSURE SENSOR (LEFT SIDE OF ENGINE COMPT)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
VBU
VCC
VSA MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Cruise control circuit, with technology package (2 of 3) -> PRESS FL
