Acura RL II (2004-2008) pnk nep vssout Wiring diagram
This page shows the only wiring diagram for the component.pnk nep vssout, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk nep vssout (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 VSS COM PPL
BLK WIRE
BLU WIRE
BRN WIRE
DRIVE CIRCUIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECPS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
ECPS INDICATOR
ECPS VALVE (LEFT SIDE OF ENGINE COMPT)
FUSE 21
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
LT BLU WIRE
LT GRN WIRE
MB MA
NEP MB-R MA-R
PCM (UNDER MIDDLE OF DASH)
PNK NEP VSSOUT WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
WHT WIRE
WLP GROUND
YEL WIRE
Go to component -> Electronic power steering circuit -> PNK NEP VSSOUT WIRE
