Acura RL II (2004-2008) outer handle light/ touch sensor/ door lock button Wiring diagrams
This page contains all the electrical diagrams for the component. outer handle light/ touch sensor/ door lock button, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram outer handle light/ touch sensor/ door lock button (1 of 2)
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR LF ANTENNA
DRIVER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S DOOR LF ANTENNA
FRONT PASSENGER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
FUSE 19
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
J/C
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
OUTER HANDLE LIGHT/ TOUCH SENSOR/ DOOR LOCK BUTTON
PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
PNK PNK WIRE
PNK WIRE
PPL
PPL 4
RED WIRE
TRUNK LID OUTER HANDLE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (4 of 5) -> OUTER HANDLE LIGHT/ TOUCH SENSOR/ DOOR LOCK BUTTON
